PCO2 iP-9200 monitor-Japan

Описание

                             GLOBAL SALES IN JAPANESE JEN , THE PRODUCT IS NOT FOR THE SERBIAN MARKET

PCO2 iP-9200 monitor-Japan:

Klasifikacija klase Upravljanje medicinskim uređajima / Specifično održavanje Medicinskih
uređaja koji upravljaju održavanjem
Broj sertifikata za medicinske uređaje 221AGBZKS00307000

Showing a trend on your monitor screen
Capturing trends on screen can be selected from 4 ranges of 15 minutes, 30 minutes, 1 hour and 2
 hours on one screen.
In any range, up to 4 ranges can be retroactively displayed on the screen. For example, when a
 two-hour trend is set, a trend trend of up to 8 hours can be confirmed on the screen

Switch to pCO2 single mode

The popular pCO2 single mode in the 9000 series can be set easily in steps of 0.5 ° C from 37 ° C to 42 ° C.

Displays the calibration progress on the monitor screen

Displays the progress of the most frequently requested calibration on the screen. Since the progress of calibration can be seen at a

glance, the end of calibration can be easily predicted.

Product Specifications:

Measurement / display range Transcutaneous oxygen partial pressure pO2: 0 to 999mmHg (orange) Transcutaneous carbon dioxide partial pressure pCO2: 1 to 199mmHg (green) Message: Alarm / operation instruction Trend graph: Real-time measurement value
Alarm measurement range Transcutaneous oxygen partial pressure pO2 Upper limit: 0 to 999 mmHg Lower limit: 0 to 999 mmHg Transcutaneous carbon dioxide partial pressure pCO2 Upper limit: 1 to 199 mmHg Lower limit: 1 to 199 mmHg
pO2 / pCO2 sensor temperature 37 ℃-45 ℃ (in 0.5 ℃ increments)
Calibration Built-in automatic calibration Two-point automatic calibration with standard gas
External output Analog: 0 to 1000mV / 0 to 150mmHg Digital: RS232C
Built-in battery Dedicated battery: 7.2V Operating time: Approximately 45 minutes
Electrical rating AC100V 50 / 60Hz, 40VA or less
Classification of equipment against electric shock Type of protection: Class I equipment Degree of protection: Type BF
Dimensions 240 (W) x 3000 (D) x 149 mm (H)
Quality 4.8 kg (including built-in battery, but excluding calibration gas cylinder and sensor)
Class Classification Managed Medical Device / Specific Maintenance Managed Medical Device
Medical device certification number 221AGBZX00307000
JMDN code 36346000
